5 Inch Color Wireless Backup Cameras Monitor 1080P Pixel With 2 Channels System

5 Inch Color Wireless Backup Cameras Monitor 1080P Pixel With 2 Channels System

Product Details:

Place of Origin: China
Brand Name: TX
Certification: FCC CE ROHS
Model Number: FX12F

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: color box
Delivery Time: 5-8 days
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 1000pcs/week
Get Best Price Contact Now

Detail Information

Viewing Angle: 160° Waterproof Rating: IP69K
Transmission Distance(barrier Free): 984ft White Balance: Auto
Screen Size: 5 Inch Color Screen Power Supply: DC+12V~+24V
Brightness: 1000 Cd/m² Night Vision Distance: 4-5m
High Light:

Wireless Backup Cameras IP69K

,

1080P Backup Camera Monitor

,

FHSS Backup Camera Monitor

Product Description

1080P Pixel 5 Inch Color Monitor Wireless Backup Cameras With 2 Channels System




Specification:

Monitor



LCD Size: 5 Inch Color Monitor
Resolution: 800 x 3(RGB)x 480
Brightness: 1000 cd/m
TV System: PAL/NTSC
Transmitted Power: 24±1dBm@Max
Operating Frequency: 2.4GHz~2.4835GHz
RX Sensitivity -85dBm@10%PER
Spread Spectrum FHSS
Video Compression H.264
Latency 160ms
Transmitting Distance 984ft line of sight
TF Card Min.8G Max.128G
Power Supply: DC+12V~+24V
Operating temperature: -20℃~+70℃
Storage temperature: -30℃~+80℃
Size 132.5x89.5x22.5mm


Camera


Image Sensor

1/2.7’’COMS HD

Viewing Angle

160°

AGC

Auto

BLC

Auto

White Balance

Auto

Operation Frequency

2.4GHz--2.4835GHz

Transmission Distance(barrier free)

300m(984ft)

Transmission Power

23dB

Latency

Less 200ms

Spread Spectrum

FHSS

RF Bit Rate

12Mbps

Minimum Illumination

0Lux

Night vision distance

4-5m

Power supply

DC 10-18V

Waterproof rating

IP69K

Operating Temperature

-20℃--70℃,RH85% MAX

Storage Temperature

-30℃--80℃,RH85% MAX

Size

85x28x27.5mm

Weight

90g


Features:

1. First 5 Inch 720P Dual-channel digital high-definition wireless DVR set.
2. Monitor built-in receiver,latency time is 130ms.
3. 720P H.264 HD DVR Recording,support playback online.make sure have evidence to follow.
4. Camera use flat line designed of cable line, power by connecting the license plate light,

it can be working a long time for rear recording and front recording.

5. Power supply of camera is DC 10-18V,built-in transmitter and antenna.
5. 160 degree full-glass wide angle lens, 200W(1080P) Pixel sensor, IP69K waterproof.anti-fog, dust-proof, scratch-proof.
6. Super wireless signal system,provide strong signal to the vehicle understand 33ft length.


Application:

The best choices of backup camera system for mini car, pickup, SUV,RV, Trailer RV.and so on with super night vision.
