FHSS 10 Inch Digital Truck Rearview Camera AHD Wireless Receiver
Product Details:
| Place of Origin: | China |
| Brand Name: | TX |
| Certification: | FCC CE ROHS |
| Model Number: | FX11GH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | color box |
| Delivery Time: | 5-8 days |
| Payment Terms: | Western Union, MoneyGram, L/C, T/T |
| Supply Ability: | 1000pcs/week |
|
Detail Information |
|||
| Operation Frequency: | 2.4GHz--2.4835GHz | Transmission Distance(barrier Free): | 300m(984ft) |
|---|---|---|---|
| Transmission Power: | 23dB | Latency: | Less Than 200ms |
| Spread Spectrum: | FHSS | RF Bit Rate: | 12Mbps |
| Minimum Illumination: | 0Lux | RX Sensitivity: | -85db |
| Operating Temperature: | -20℃--70℃，RH85% MAX | Storage Temperature: | -30℃--80℃，RH85% MAX |
| High Light: | FHSS Truck Rearview Camera,FHSS Wireless Rear View Camera,12Mbps Wireless Rear View Camera |
||
Product Description
FHSS 10 Inch Digital Truck Rearview Camera AHD Wireless Receiver
Truck Rearview Camera 1080P 10" Digital Rearview Dashcam AHD Wireless Receiver
Specification:
Camera
| Sensor | 1/2.7’’COMS HD |
| Viewing Angle | 120° |
| AGC | Auto |
| BLC | Auto |
| White Balance | Auto |
| Operation Frequency | 2.4GHz--2.4835GHz |
| Transmission Distance(barrier free) | 300m(984ft) |
| Transmission Power | 23dB |
| Latency | Less 200ms |
| Spread Spectrum | FHSS |
| RF Bit Rate | 12Mbps |
| Minimum Illumination | 0Lux |
| Night vision distance | 4-5m |
| Power supply | DC 10-18V |
| Waterproof rating | IP69K |
| Operating Temperature | -20℃--70℃,RH85% MAX |
| Storage Temperature | -30℃--80℃,RH85% MAX |
| Size | 85x28x27.5mm |
| Weight | 90g |
Receiver
| Operation Frequency | 2.4GHz--2.4835GHz |
| Transmission Power | 23dB |
| RX Sensitivity | -85dB |
| RF Bit Rate | 12Mbps |
| Spread Spectrum | FHSS |
| Video output format | 1080p |
| Coding Decompression method | H.264 |
| Power Supply | DC 10-30V |
| Size | 92x68x43mm |
| Weight | 185g |
10 Inch Rearview Mirror
| Built-in image sensor | 2 Mega pixel |
| Viewing angle | 130° |
| Video resolution | 1920*1080,S/30 frame |
| Storage compression method | MJPEG |
| Video format | MOV |
| Touch TP | Support, single touch |
| Storage Temperature | -20℃-70℃ |
| Operating Temperature | 0℃-50℃ |
| Operating humidity | 15-65%RH |
| SD Card | 128GB Micro SD Card[TF] |
| Standard Voltage | DC5V |
Features:
1. HD digital wireless and AHD Backup camera KIT for Mirror dash cam.
2. Easy to install and save space.
3. Brand-new and unique product design for camera and receiver.
4. Camera with 120º Wide-angle HD lens,200W(1080P)Pixel sensor,display high quality image.
5. Camera has 6 LEDs highlight light,Smart LED light can work for photosensitive and light complement automatically.
6. Steady feature of camera,can work long time for driving record monitoring.
7. Car-charger integrated machine of receiver,can power by connecting the car cigarette lighter directly.more convenient.
8. 10 Inch rearview mirror,built-in1080P Front transmitter and AHD signal input,ultra-clear image.wide view angle 130º
Competitive advantage:
1. Stable quality(CE,FCC,ROHS)
2. Most competitive price
3. On time delivery
4. All products must test one by one waterproof resistance and high/low temperature resistance
5. Warranty: 12 months
6. OEM,ODM welcome
