DVR Function Night Vision Backup Cameras 10 Inch Mirror Dashcam
Product Details:
| Place of Origin: | China |
| Brand Name: | TX |
| Certification: | FCC CE ROHS |
| Model Number: | FX11GH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | color box |
| Delivery Time: | 5-8 days |
| Payment Terms: | Western Union, MoneyGram, L/C, T/T |
| Supply Ability: | 1000pcs/week |
|
Detail Information |
|||
| Material: | Metal | Operating Temperature: | -20℃--70℃，RH85% MAX |
|---|---|---|---|
| Storage Temperature: | -30℃--80℃，RH85% MAX | Camera Size: | 85x28x27.5mm |
| Coding Decompression Method: | H.264 | Video Output Format: | 1080p |
| Receiver Weight: | 185g | Waterproof Rating: | IP69K |
| High Light: | FCC Night Vision Backup Cameras,DC5V Night Vision Backup Cameras,IP69K Dash Reverse Camera |
||
Product Description
DVR Function Night Vision Backup Cameras 10 Inch Mirror Dashcam
Night Vision Backup Cameras 10 Inch Mirror Dashcam AHD Receiver DVR Function
Specification:
Camera
| Sensor | 1/2.7’’COMS HD |
| Viewing Angle | 120° |
| AGC | Auto |
| BLC | Auto |
| White Balance | Auto |
| Operation Frequency | 2.4GHz--2.4835GHz |
| Transmission Distance(barrier free) | 300m(984ft) |
| Transmission Power | 23dB |
| Latency | Less 200ms |
| Spread Spectrum | FHSS |
| RF Bit Rate | 12Mbps |
| Minimum Illumination | 0Lux |
| Night vision distance | 4-5m |
| Power supply | DC 10-18V |
| Waterproof rating | IP69K |
| Operating Temperature | -20℃--70℃,RH85% MAX |
| Storage Temperature | -30℃--80℃,RH85% MAX |
| Size | 85x28x27.5mm |
| Weight | 90g |
Receiver
| Operation Frequency | 2.4GHz--2.4835GHz |
| Transmission Power | 23dB |
| RX Sensitivity | -85dB |
| RF Bit Rate | 12Mbps |
| Spread Spectrum | FHSS |
| Video output format | 1080p |
| Coding Decompression method | H.264 |
| Power Supply | DC 10-30V |
| Size | 92x68x43mm |
| Weight | 185g |
10 Inch Rearview Mirror
| Built-in image sensor | 2 Mega pixel |
| Viewing angle | 130° |
| Video resolution | 1920*1080,S/30 frame |
| Storage compression method | MJPEG |
| Video format | MOV |
| Touch TP | Support, single touch |
| Storage Temperature | -20℃-70℃ |
| Operating Temperature | 0℃-50℃ |
| Operating humidity | 15-65%RH |
| SD Card | 128GB Micro SD Card[TF] |
| Standard Voltage | DC5V |
Features:
1. First item 10 Inch AHD digital wireless streaming rear view mirror DVR
2. 10 Inch big touch screen and Anti-glare screen.Built-in front digital wireless transmitter.
3. support two cameras,rear and front image 1080P recording.
4. Front and back camera split screen display at the same time.support playback online.
5. Camera use flat line designed of cable line, power by connecting license plate light ,and can be working a long time for rear recording.
6. With data line 3.5M, apply to different type of vehicles for wiring.
7. Car charger receiver function: Trigger the rearview mirror reversing line. Spin, Pair, Power on/off, N/P Switch, Factory resetting
8. Apply to vehicles: Small bridge car .pickup ,SUV,RV.
Notices:
- Please use this product within the specified voltage range.
- Pay attention to the positive poles of the power cord. If the positive and negative sides are connected in reverse, it may burn out.
- If smoke or burning smell is detected, please disconnect the power immediately.
- Please wrap the cable with tape when connecting it.
- Please fix the product firmly before use.
- If you do not understand the installation process, please consult professionals.
Company Service:
As one of the biggest supplier for car electronic products in Shenzhen China, Our products are sold all over the world, our company pay attention to produce goods for RV design, highly use for reversing, driving and parking of RV/Trailer RV. and also providing OEM&ODM service for OEM&ODM customer.
1. Reply your enquiry within 24 working hours. Best service of after-sales after shipment.
2. Experienced staffs answer all your questions professional, have rich experiences in backup camera and monitor.
3. Customized design is available. OEM&ODM are welcome, the best vehicle rear view camera.
4. Exclusive, considerate and unique solution can be provided to our customers by our well-trained and professional engineers and
staffs.
5. Quality control: all certificates are available, Such as CE,FCC,ROHS.
