7 Inch LCD color Monitor Car Rear View Camera Night Vision 33ft

7 Inch LCD color Monitor Car Rear View Camera Night Vision 33ft

Product Details:

Place of Origin: China
Brand Name: TX
Certification: FCC CE ROHS
Model Number: FX14L

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: color box
Delivery Time: 5-8 days
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 1000pcs/week
Get Best Price Contact Now

Detail Information

Screen Size: 7 Inch Color Monitor Operating Frequency: 2.4GHz~2.4835GHz
Brightness: 900 Cd/m² Channel: 4 Channels Max
Transmission Distance: 1650ft Operating Temperature: -20℃--70℃
Storage Temperature: -30℃--80℃ Waterproof Rating Level: IP69k
Night Vision Distance: 33ft Latency: Less Than 200ms
High Light:

IP69k Car Rear View Camera

,

1650 ft Car Rear View Camera

,

Night Vision 33ft Wireless Rearview Camera

Product Description

7 Inch LCD color Monitor Car Rear View Camera Night Vision 33ft



Wireless Rearview Camera 7 Inch LCD Monitor DVR Adjustable Bracket 4 Cameras

Specification:



Monitor


Screen Size 7 inch Color Monitor
Operating Frequency 2.4GHz~2.4835GHz
Resolution 1024 x 3(RGB) x 600
Video Format MP4
Built-in DVR recording Holding up to 16G/32G/64G/128G SD Cards
Brightness 900 cd/m²
Channel 4 channels Max
Transmission Distance 1650ft
Power consumption Max:6W
Power Supply DC 12-24V
Operating temperature -20℃--70℃
Storage temperature -30℃--80℃
Outer Dimension 184mm(W)X129mm(H)X26mm(D)


Cameras(FX301T+FX302T+FX303T)



Viewing Angle 120°
Image Device 1/2.7" COMS (HD)
IR Control SMART IR-CUT 650nm Day/850nm Night Auto
Waterproof level IP69k
Transmission Distance(barrier free) 1650ft
Night Vision Distance 33ft
Latency less than 200ms
Power Supply DC+12V
Power Consumption 150mA/12V
Transmission Power 26dB
Operating Temperature -20℃--70℃,RH85% MAX
Storage Temperature -30℃--80℃,RH85% MAX
Weight 430g
Spread Spectrum FHSS
Minimum Illumination 0Lux


FX922T(Smallest camera)



Image Sensor 1/2.7’’COMS HD
Viewing Angle 160°
AGC Auto
BLC Auto
White Balance Auto
Operation Frequency 2.4GHz--2.4835GHz
Transmission Distance(barrier free) 300m(984ft)
Transmission Power 23dB
Latency Less 200ms
Spread Spectrum FHSS
RF Bit Rate 12Mbps
Minimum Illumination 0Lux
Night vision distance 4-5m
Power supply DC 10-18V
Waterproof rating IP69K
Operating Temperature -20℃--70℃,RH85% MAX
Storage Temperature -30℃--80℃,RH85% MAX
Size 85x28x27.5mm
Weight 90g


Features:

1. 7 Inch RV 4 cameras 720P digital HD wireless DVR set.
2. With 6 highlight LED Lamp. one rear camera of Warning Light and two sides of left and right width light, With silicone mold.
3. Support multi-channel camera display, can support up to 4 channel split screen.
4. 7 inch IPS screen 1024*600 resolution 900cd/ m².
5. 720P H.264 HD DVR Video recording ,support playback online.
6. Self-defining reversing line setting,
7. Wireless signal open distance can reach up to 1650ft(500m), Transmit power is 26DBM
8. Camera use Structural waterproofing process, waterproof IP69K, waterproof droplets, anti-fog, dust-proof, scratch-proof.
9. 120 degree full-glass wide angle lens, 200W(1080P) Pixel Photosensitive element(Sensor), Super strong 11pcs high power infrared light. IR-CUT smart switch night vision, night vision distances can reach up to 10m.
10. The FX922T camera power cord use flat wire design, and use for driving wireless rear-view recorder by connecting the license plate light.(Can install car license plate and RV side door)
11. Combine content: one monitor with four cameras(FX909R+FX301T+FX302T+FX303T+FX922T)
12. Apply to vehicles: RV, Trailer RV

OEM:

Support your creative idea to develop new product(Product appearance design, functional design, Logo customization, packing customization etc.)
We provide 12 months quality guarantee period for each products.
We offer one year warranty on all products purchased from us. If your item has any warranty issue please contact us for a satisfying solution.

Competitive advantage:

1. Stable quality(CE,FCC,ROHS)
2. Most competitive price
3. On time delivery
4. All products must test one by one waterproof resistance and high/low temperature resistance
5. Warranty: 12 months
6. OEM,ODM welcome
